Product Information |
| Manufacturer: |
US GlobalSat |
Category: |
GPS Units |
Type: |
Mobile Computer GPS |
| Model: |
BT-335 |
SKU: |
BT335 |
UPC: |
795945035605 |
| Announced: |
August 1, 2006 |
First Shipped: |
August 1, 2006 |
Weight: |
0.825 lbs. |
Manufacturer Description |
The BT-335 Bluetooth GPS receiver from GlobalSat utilizes the same platform as the ever popular BT-338 GPS receiver, which set the original benchmark standards for all SiRF III GPS receivers. With new improvements to it's functionally and 16Mbit of internal memory, the BT-335 now can simultaneously record and store up to 60,000 waypoints as it navigates to various destinations when used with your favorite software.
|
Features & Tips |
Here is a listing we have put together of some of the common BT335 BT GPS Datalogger features,
along with a few user tips that you may find of help for this particular item. |
BT-335 Performance
Specifications
|
| GPS Chipset |
SiRF Star III |
| General |
L1 (1575.42 MHz) C/A code |
| Accuracy |
5 m with DGPS (WAAS)
Velocity:0.1 m/s
Time: 1ms RMS |
| Aquisition |
Reacuisition: 0.1 sec
Hot Start: 1 sec
Warm Start: 38 sec
Cold Start: 42 sec |
| Sensitivity |
Tracking; -159 dBm |
BT-335 Protocol
|
| GPS Protocol
|
NMEA 0183 (Default), SiRF binary (Secondary) |
|
GPS Output Data
|
SiRF binary >> position, velocity,
altitude
NMEA 0183 V2.2 protocol |
|
GPS Transfer Rate
|
38400,n,8,1 for NMEA (Default) via Bluetooth |
|
Connection
|
Bluetooth Serial Port Profile (SPP) |
BT-335 Electrical Characteristics
|
| Prime Power
|
NMEA 0183 (Default), SiRF binary (Secondary) |
|
External Power
|
SiRF binary >> position, velocity,
altitude |
|
Battery Capacity
|
38400,n,8,1 for NMEA (Default) via Bluetooth |
|
Battery Life
|
25 Hours continuous use typical |
| Operating Current
|
85mA |
BT-335 Physical Characteristics
|
| Enclosure
|
Durable Polycarbonate |
|
Dimensions
|
2.85" x 1.6" x 1"
(72.5mm x 40.4mm x 26mm) |
| Weight
|
2.64 Ounces (75 g) |
BT-335 Enviromental Specifications
|
| Operating Temperature
|
14F ~ 149F (-10C ~ 60C) |
|
Storage Temperature
|
-4F ~ 158F (-20C ~ 70C) |
|
Operation Humidity
|
5% to 95% non-condensing |
|
