This item has been discontinued by the manufacturer.
Accessories may still
be available for this item. Click to view accessories. |
| |
|
What's Included In The Box? |
The US GlobalSat BT328 Bluetooth GPS ships with the following items included: - BT-328RB Bluetooth GPS Receiver
- 12VDC Car Charger
- CD-ROM (User Manual & GPS Info Test Utility)
|
Product Information |
| Manufacturer: |
US GlobalSat |
Category: |
GPS Units |
Type: |
Mobile Computer GPS |
| Model: |
06-BT328-M |
SKU: |
BT328 |
UPC: |
795945031508 |
| Announced: |
August 1, 2006 |
First Shipped: |
August 1, 2006 |
Weight: |
0.563 lbs. |
Manufacturer Description |
Accurate, Lightweight, Affordable. The BT-328RB Bluetooth GPS receiver uses the SiRF GSC2 low-power chip-set to combine performance with low cost. This combination has created the perfect entry-level Bluetooth GPS at a very attractive price. Compatible with just about any device using Serial Port Protocol (SPP) Bluetooth, the BT-328RB can provide accurate GPS positioning information for up to 16 hours of continuous use from its internal Li-ion rechargeable battery.
Use the BT-328RB with your favorite application, whether it be vehicle navigation on a laptop, Topo maps on a PDA or getting directions from a Smartphone, the BT-328RB rivals the accuracy of many higher priced GPS receivers at only a fraction of the cost.
The BT-328RB is the perfect combination of technology and design as has become one of the most popular GPS devices in it's class today.
BT-328RB Package Contents:
- BT-328RB Bluetooth GPS Receiver
- 12VDC Car Charger
- CD-ROM (User Manual and GPS Info Test Utility)
- Supports Mac/ PC/ Palm/ BlackBerry/ WM
|
Features & Tips |
Here is a listing we have put together of some of the common BT328 Bluetooth GPS features,
along with a few user tips that you may find of help for this particular item. |
BT-328 Performance
Specifications
|
| GPS Chipset |
SiRF Star III |
| General |
L1 (1575.42 MHz) C/A code |
| Accuracy |
5 m with DGPS (WAAS)
Velocity:0.1 m/s
Time: 1ms RMS |
| Aquisition |
Reacuisition: 0.1 sec
Hot Start: 8 sec
Warm Start: 38 sec
Cold Start: 42 sec |
| Sensitivity |
Tracking; -159 dBm |
BT-328 Protocol
|
| GPS Protocol
|
NMEA 0183 (Default), SiRF binary (Secondary) |
|
GPS Output Data
|
GGA, GSA, GSV, RMC, VTG, GLL (VTG and GLL are optional) |
|
GPS Transfer Rate
|
38400,N,8,1 for NMEA (Default) via Bluetooth |
|
Connection
|
Bluetooth V1.2 Compliant |
BT-328 Electrical Characteristics
|
| Prime Power
|
NMEA 0183 (Default), SiRF binary (Secondary) |
|
External Power
|
SiRF binary >> position, velocity,
altitude |
|
Battery Capacity
|
38400,n,8,1 for NMEA (Default) via Bluetooth |
|
Battery Life
|
16 Hours continuous use typical |
| Operating Current
|
85mA |
BT-328 Physical Characteristics
|
| Enclosure
|
Durable Polycarbonate |
|
Dimensions
|
67.5mm x 45mm x 17mm
|
| Weight
|
2.64 Ounces (75 g) |
BT-328 Enviromental Specifications
|
| Operating Temperature
|
14F ~ 149F (-10C ~ 60C) |
|
Storage Temperature
|
-4F ~ 158F (-20C ~ 60C) |
|
Operation Humidity
|
5% to 95% non-condensing |
|
