RAM Mount Aluminum TomTom GO 520 720 920 Zinc Coated U-Bolt Motorcycle Short Mount


RAM Mount TomTom GO 520 720 920 Zinc Coated U-Bolt Short Mount
Customer Images
Share your images and get a
free gpscity.ca t-shirt!
Not yet rated.    Email:  Email the RAM Mount TomTom GO 520 720 920 Zinc Coated U-Bolt Short Mount page     Print:  Print the RAM Mount TomTom GO 520 720 920 Zinc Coated U-Bolt Short Mount page
See more RAM Mount items.

List Price: $45.95CDN
Our Price: $37.95CDN (and this item ships for $4.99. Learn more.)
You Save: $8.00CDN (17%)

Availability:

In Stock.
Ships from Calgary tomorrow, February 7.


Qty:

Model: RAM Mount TomTom GO 520 720 920 Zinc Coated U-Bolt Short Mount
Part No: RAM-B-149Z-A-TO6
Condition: Brand New, Lifetime Manufacturer Warranty (max 3 years on electronics & lenses)
Price Match: Get an Instant Price Match in about 5 minutes (during business hours).

Learn More with our Instructional Videos   (More GPS City videos. Visit our Youtube channel.)
RAM TomTom GO Cradle: In Use (RAM-HOL-TO6) Video
RAM TomTom GO Cradle: In Use (RAM-HOL-TO6)
(5,412 views)
RAM Diamond Plate: Overview (RAM-B-238U) Video
RAM Diamond Plate: Overview (RAM-B-238U)
(20,196 views)
RAM AMPS Hole Pattern: Explained Video
RAM AMPS Hole Pattern: Explained
(6,503 views)
RAM Mount Plate: Overview (RAM-B-347) Video
RAM Mount Plate: Overview (RAM-B-347)
(3,866 views)
RAM Short Arm: Overview (RAM-B-201U-A) Video
RAM Short Arm: Overview (RAM-B-201U-A)
(3,423 views)

RAM Mount Sub-Component Breakdown
Here are the sub-component parts that make up this item:

TomTom GO 520 720 920 Cradle RAM-HOL-TO6U
+
Diamond Plate with 1 inch Ball RAM-B-238U
+
Short Arm B-Socket RAM-B-201U-A
+
Zinc U-Bolt Motorcycle Mount Base RAM-B-231ZU

What's Included In The Box?

The RAM Mount TomTom GO 520 720 920 Zinc Coated U-Bolt Short Mount ships with the following items included:


Product Information
Manufacturer: National Products, Inc Category: All Purpose Mounts Type: GPS Mounts
Model: RAM-B-149Z-A-TO6 SKU: RAMB149ZATO6 UPC:
Announced: January 17, 2008 First Shipped: March 3, 2008 Weight: 0.700 lbs.

RAM Mount TomTom GO 520 720 920 Zinc Coated U-Bolt Short Mount Description
The RAM-B-149Z-A-TO6 TomTom GO 520/520T, GO 720/720T and GO 920/920T Series Short Motorcycle RAM Mount is a Marine Grade Aluminum Mount with a Zinc Coated U-Bolt Rail Base and RAM Custom Plastic Cradle. The mount is designed with a RAM 1 inch diameter patented rubber ball and socket system that has adjustment point at the cradle and base. With a twist of the short arm knob, you can move the TomTom GO 520/520T, GO 720/720T and GO 920/920T Series mount to your optimum viewing position.

TomTom GPS Mount Options:


To help ensure you have the TomTom GO 720 and GPS 920 Mount you require, take a look at the list of available RAM TomTom GPS mounts on the TomTom GO 720 and GPS 920 Mount Page. Here you can select from suction cup GPS mounts, flat surface screw down GPS mounts, GPS car mounts, non skid weighted GPS mounts and more bundled with the RAM-HOL-TO6 TomTom GO 720 and GPS 920 Cradle.

TomTom GPS Mount Cradle Design:


The RAM-HOL-TO6 RAM Mount High Strength Plastic Cradle is designed to hold the following TomTom GPS units,
  • TomTom GO 520
  • TomTom GO 520T
  • TomTom GO 720
  • TomTom GO 720T
  • TomTom GO 920
  • TomTom GO 920T
All cables can stay connected to the unit while in the RAM cradle.

TomTom GPS Mount Cradle Plate:


The RAM-B-238 Marine Grade Aluminum Diamond Plate is designed to connected to the back of the mount cradle. The diamond plate has a 1.0 inch diameter rubber ball connected at right angles to the plate, which connects directly to the 1 inch arm socket. The cradle includes the required hardware to connect the plate to the cradle. For a layout of the hole spacing and 1.0 inch rubber ball location, take a closer look with the RAM-B-238 Design Drawings (pdf file).

TomTom GPS Mount Arm Design:


The RAM-B-201-A RAM Mount Dual Socket Short Arm is a 1 inch B size Ball Dual Socket Arm made of Marine Grade Aluminum. The arm is 1.75 inches long between socket centers and is finished with a Black Powder Coating. The side of the arm includes a tightening knob which allows you to open and close the socket ends. For a layout of the dimensions RAM-B-201A arm, take a closer look with the RAM-B-201A Design Drawings (pdf file).

TomTom GPS Mount Base Design:


The RAM-B-231Z RAM Mount Powder Coated Marine Grade Aluminum Rail Base has a 1.0 inch diameter Rubber Ball designed to sit at right angles to the mounting rail. The Zinc Coated metal U-Bolt and nuts included are designed it fit on most motorcycle round handlebars, or any circular rail or pipe with diameter from 3/4 to 1.0 inch.

To mount the rail base, place the top of the base on the rail and then slide the u-bolt around the rail, into the holes in the base top. Now tighten the screws onto the u-bolt until the base is clamped firmly. If you desire, you can now slot the black rubber covers over the exposed ends of the u-bolt.

Note: If you are looking to use this mount in the elements, we suggest the RAM-B-231 Stainless Steel U-Bolt Mount.


RAM Mount TomTom GO 520 720 920 Zinc Coated U-Bolt Short Mount Features & Tips
Here is a listing we have put together of some of the common

TomTom GO 520 720 920 Zinc Coated U-Bolt Short Mount features

, along with a few user tips that you may find of help for this particular item.
  • Warranty: Manufacturer's Life Time Warranty.
  • Cradle Design: Custom Cradle for TomTom GO 520/520T, GO 720/720T and GO 920/920T Series.
  • Cradle Material: Black High Strength Composite Plastic.
  • Mount Material: Black Powder Coated Marine Grade Aluminum.
  • Mount Ball Size: RAM 1 inch Solid Rubber Ball.
  • Pivot Point Design: RAM Patented 1 inch Rubber Ball and Socket Joint.
  • Arm Type: RAM Arm with Dual 1 inch Sockets.
  • Arm Length: Short length of 1.75 inches between socket centers.
  • Base Type: Motorcycle Handlebar Base or Universal Round Pipe Base with Zinc Coated U-Bolt. (0.75 to 1 inch wide)
  • Common Applications:
    • Motorcycle and ATV Mounts: Attaching to handlebars.
    • Hiking Mounts: Attaching to hiking staffs.
    • General Mounts: Attaching to available pipes or poles.
