Product Detail & Documentation (all files in PDF format)
Manufacturer
RAM Mount
Category
PDA Mounts
Model
RAM-B-101U-TD1
SKU
RAMB101TD1
Weight
0.744 lbs.
Share this item:
Need Assistance? We're here to help. (That's the GPS City Difference!)
For quick help selecting the right GPS unit, try our
GPS Selector Tool,
check specifications, or
compare GPS units. If you have a specific question about an
item, try entering your question using the
Q&A (Questions & Answers) section above - we usually respond on the same or next day. During our office hours 9AM - 6PM MDT, Mon-Fri, you can contact us using
, or reach us by phone at 1-866-GPS-CITY.
What's Included With The RAM Mount TDA Recon PDA Screw Down Plate Mount? The RAM Mount TDA Recon PDA Screw Down Plate Mount ships with the following items included:
RAM Mount TDA Recon PDA Screw Down Plate Mount Description The RAM-B-101-TD1 TDS Recon PDA RAM Mount is a Marine Grade Aluminum Screw Down Plate Mount. It consists of the 1 inch diameter ball and socket system with RAM Mount Plastic Cradle for the TDS Recon PDA Series.
TDS Recon PDA Mount Cradle Design:
The RAM-HOL-TD1 RAM Mount High Strength Plastic Cradle is designed to hold the following TDS PDA units,
TDS Recon PDA
The back of the cradle is connected to a round plate with ball. The ball gives the cradle the ability to connect to the RAM arm on this mount and also creates a ball and socket joint allowing you to move the cradle into many different viewing locations. All cables can stay connected to the TDS Ranger while in the RAM cradle.
TDS Recon PDA Mount Arm Design:
The RAM-B-201 RAM Mount Marine Grade Aluminum Dual Socket Arm is a 1 inch B size Ball Socket Arm with open socket ends. The arm is 3.0 inches long between socket centers and is finished with a Black Powder Coating. The side of the arm includes a tightening knob which allows you to open and close the socket ends. For a layout of the dimensions RAM-B-201 arm, take a closer look with the RAM-B-201 Design Drawings (pdf file).
TDS Recon PDA Mount Base Design:
The RAM-B-202 RAM Mount Marine Grade Aluminum Screw Down Plate has a 1.0 inch diameter Rubber Ball connected at right angles to a 2.5 inch diameter Plate. The plate has pre-drilled holes in the base plate, including the universal AMPS hole pattern. For a layout of the hole spacing and 1.0 inch rubber ball location, take a closer look with the RAM-B-202 Design Drawings (pdf file).
Mount Base Mounting Solutions:
Mounting hardware is NOT included with the purchase of the RAM-B-202. A semi-permanent solution for mounting this base is by using the RAM double sided adhesive disk (RAM-202PSA). The disk will hold the RAM-B-202 base in many different locations without screws.
TDS Recon PDA Mount Options:
To help ensure you have the TDS Recon Mount you require, take a look at the list of available RAM TDS PDA mounts on the TDS Recon Mount List Page. Here you can select from pole/rail TDS mounts, suction cup TDS mounts, flat surface screw down TDS mounts and more bundled with the TDS Recon Cradle.
