See more RAM Mount items. |
| |
| List Price: |
$71.31CDN |
| Our Price: |
$53.95CDN (Ships for $5.99. Restrictions apply.) |
| You Save: |
$17.36CDN (24%) |
Availability: |
In Stock.
Ships from Calgary on Monday, May 28. |
|
| |
| Model: |
RAM Mount RAM-B-148-UN2 |
| Part No: |
RAM-B-148-UN2U (also RAM-B-148-UN2) |
| Condition: |
Brand New, Lifetime Manufacturer Warranty (max 3 years on electronics & lenses) |
|
| Price Match: |
Get an Instant Price Match in about 5 minutes (during business hours). |
|
Learn More with our Instructional Videos |
| » See our list of GPS City videos. Visit our Youtube channel. |
RAM Universal Grip Cradle: In Use (RAM-HOL-UN2)
(1,652 views) |
RAM Universal Grip Cradle: Dimensions (RAM-HOL-UN2)
(795 views) |
RAM Diamond Plate: Overview (RAM-B-238U)
(21,594 views) |
RAM AMPS Hole Pattern: Explained
(8,013 views) |
RAM Mount Plate: Overview (RAM-B-347)
(4,884 views) |
|
What's Included In The Box? |
The RAM Mount RAM-B-148-UN2 ships with the following items included: |
Product Information |
| Manufacturer: |
National Products, Inc |
Category: |
All Purpose Mounts |
Type: |
Universal Mounts |
| Model: |
RAM-B-148-UN2U |
SKU: |
RAMB148UN2 |
UPC: |
|
| Announced: |
November 25, 2004 |
First Shipped: |
October 11, 2004 |
Weight: |
0.862 lbs. |
Manufacturer Description |
The RAM-B-148-UN2U Universal Cradle RAM Mount is a Marine Grade Aluminum Mount with a Large 4 inch diameter Suction Cup Base and RAM Side Clamping Plastic Cradle. The mount is designed with a RAM 1.0 inch diameter patented rubber ball and socket system that has adjustment point at the cradle and base. The 1.0 inch diameter B size ball and socket system give the mount an approximate holding weight of up to 5 lbs. With a twist of the arm knob, you can move the Universal Cradle Mount to your optimum viewing position.
Universal Mount Options:
 To help ensure you have the Universal Mount you require, take a look at the list of available RAM universal medium clamping cradle mounts on the RAM-HOL-UN2 Series of medium universal cradles and mounts Page. Here you can select from suction cup universal mounts, flat surface screw down universal mounts, universal car mounts, non skid weighted universal mounts and more bundled with the RAM-HOL-UN2 Universal Series Cradle. Alternatively, you can review the complete list of RAM universal cradles and mounts.
Universal Mount Cradle Design:
 The RAM-HOL-UN2 Medium RAM Plastic Side Clamping Cradle is designed to hold a large amount of different kinds of cell phones and electronic devices.
Using the Cradle:
This cradle has padded locking side clamps that close tightly on the item you want to hold. To release the clamp hold, simply press the button found at the bottom of the back of the cradle which will spring the clamps open. At the base of the cradle is a small support to hold the bottom of the item securely in the cradle. This RAM universal side clamping cradle is designed to be used in a closed cabin, low vibration environment. This system is not recommended as a motorcycle mount.
Universal Cradle Dimensions:
- Minimum Grip Width: 1.5''
- Maximum Grip Width: 2.6''
- Side Clamp Height: 1.88''
- Side Clamp Depth: 1.13''
- Cradle Spine Height: 3.68''
- Cradle Spine Width: 2.0''
NOTE: The top of the cradle is open, so the items in the cradle can be larger than the height of the cradle.
Universal Mount Cradle Plate:
 The RAM-B-238 Marine Grade Aluminum Diamond Plate is designed to connected to the back of the mount cradle. The diamond plate has a 1.0 inch diameter rubber ball connected at right angles to the plate, which connects directly to the 1 inch arm socket. The cradle includes the required hardware to connect the plate to the cradle. For a layout of the hole spacing and 1.0 inch rubber ball location, take a closer look with the RAM-B-238 Design Drawings (pdf file).
Universal Mount Arm Design:
 The RAM-B-201 RAM Mount Marine Grade Aluminum Dual Socket Arm is a 1 inch B size Ball Socket Arm with open socket ends. The arm is 3.0 inches long between socket centers and is finished with a Black Powder Coating. The side of the arm includes a tightening knob which allows you to open and close the socket ends. For a layout of the dimensions RAM-B-201 arm, take a closer look with the RAM-B-201 Design Drawings (pdf file).
Universal Mount Base Design:
 The large 4 inch Rubber Suction Cup base has a 1.0'' diameter Rubber Ball connected at right angles. The suction cup is designed to hold on any smooth non-porous surface, but for best result, mount the suction cup on a glass surface ¹ . For a layout of the suction cup dimensions and design, take a closer look with the RAM-B-224 Large Suctiobn Cup Base Design Drawings (pdf file).
¹ Important legal note to California and Minnesota Drivers
Note: Overtime the suction cup may become dirty, and not hold as well. If this happens, you will need to wash it in warm soapy water, and the mounting surface may need to be wiped with a cleaner (alcohol works best). Be sure to test a small area of the mounting surface before applying a cleaner as they can mark or discolor some materials (like plastic).
|
Features & Tips |
Here is a listing we have put together of some of the common RAM-B-148-UN2 features,
along with a few user tips that you may find of help for this particular item. | - Warranty: Manufacturer's Life Time Warranty.
- Cradle Design: Universal Side Clamping Cradle.
- Cradle Material: Black High Strength Composite Plastic.
- Mount Material: Black Powder Coated Marine Grade Aluminum.
- Mount Ball Size: RAM 1 inch Solid Rubber Ball.
- Pivot Point Design: RAM Patented 1 inch Rubber Ball and Socket Joint.
- Arm Type: RAM Arm with Dual 1 inch Sockets.
- Arm Length: Standard length of 3 inches between socket centers.
- Base Type: Round 4 inch diameter rubber suction cup.
- Common Applications:
- Vehicle Mounts: Attaching to vehicle windshield.
- Aviation Mounts: Attaching to windshield.
|
