Customer Images
Share your images and get a
free gpscity.ca t-shirt!
|
Not yet rated. Email:
 Print:
See more RAM Mount items. |
| |
| List Price: |
$353.24CDN |
| Our Price: |
$152.95CDN |
| You Save: |
$200.29CDN (57%) |
Availability: |
In Stock.
Ships from Calgary on Monday, May 28. |
|
| |
| Model: |
RAM Mount Motion Computing LE1600 and LE1700 Vehicle Floor Mount |
| Part No: |
RAM-316-3-MOT8 |
| Condition: |
Brand New, Lifetime Manufacturer Warranty (max 3 years on electronics & lenses) |
|
| Price Match: |
Get an Instant Price Match in about 5 minutes (during business hours). |
|
Learn More with our Instructional Videos |
| » See our list of GPS City videos. Visit our Youtube channel. |
RAM Round Plate: Overview (RAM-202U)
(3,799 views) |
RAM AMPS Hole Pattern: Explained
(8,013 views) |
RAM Mount Plate: Overview (RAM-B-347)
(4,884 views) |
Check out our
channel. | |
|
What's Included In The Box? |
The RAM Mount Motion Computing LE1600 and LE1700 Vehicle Floor Mount ships with the following items included: |
Product Information |
| Manufacturer: |
National Products, Inc |
Category: |
All Purpose Mounts |
Type: |
Tablet Mounts |
| Model: |
RAM-316-3-MOT8 |
SKU: |
RAM316-3MOT8 |
UPC: |
793442910647 |
| Announced: |
March 20, 2008 |
First Shipped: |
May 1, 2008 |
Weight: |
5.619 lbs. |
Manufacturer Description |
The RAM-316-3-MOT8 Motion Computing LE1600 and LE1700 Tablet PC Series Universal Vehicle Floor RAM-POD Mount is a Marine Grade Aluminum with a RAM Custom Plastic Cradle. The mount is designed with a 1.5 inch diameter RAM ball and socket system that has adjustment points at the cradle and top of Aluminum Rigid Flexible Rod Tri-Pod. With a twist of the arm knob, you can move the Motion Computing LE1600 and LE1700 Tablet PC mount to your optimum viewing position.
Note: This mount does not require any drilling for installation.
Motion Computing Tablet Mount Options:
To help ensure you have the Motion Computing LE1600 and LE1700 Tablet Mount you require, take a look at the list of available RAM Tablet mounts on the Motion Computing LE1700 Tablet Mount Page. Here you can select from suction cup tablet mounts, flat surface screw down tablet mounts, tablet aviation mounts, non skid weighted tablet mounts and more bundled with the Motion Computing LE1600 and LE1700 Tablet Cradle.
Motion Computing Tablet Mount Cradle Design:
The RAM-HOL-MOT8 High Strength Plastic Cradle is designed to hold the Motion Computing LE1600 and LE1700 Tablet (12.1'' Screen). All cables can stay connect to the tablet when in the cradle. To place the Motion LE1600 or LE1700 Tablet PC Computer into the cradle, you must place the bottom of the tablet in the cradle corner supports. Next, you lay the tablet back into the top of the cradle until the top clip clicks over the top of the tablet, holding it firmly in the cradle.
Motion Computing Tablet Mount Cradle Plate:The RAM-2461 Marine Grade Aluminum 75mm VESA Plate is designed to connected to the back of the mount cradle with a standard 75m VESA hole pattern. The square plate has a 1.5 inch diameter rubber ball connected at right angles to the plate, which connects directly to the 1.5 inch arm socket. The cradle includes the required hardware to connect the plate to the cradle. For a layout of the hole spacing and 1.5 inch rubber ball location, take a closer look with the RAM-2461 Design Drawings (pdf file).
Motion Computing Tablet Mount Arm Design:
 The RAM-201 RAM Mount Dual Socket Arm is a 1.5 inch C size Ball Socket Arm made of Marine Grade Aluminum. The arm is 4.63 inches long between socket centers and is finished with a Black Powder Coating. The side of the arm includes a tightening knob which allows you to open and close the socket ends. For a layout of the dimensions RAM-201 arm, take a closer look with the RAM-201 Design Drawings (pdf file).
Motion Computing Tablet Mount Base Design:The RAM POD III is a universal base which allows you to mount a large device like a laptop or tablet PC in your car safely and securely. The mount bolts to the seat rail bolts of the passenger seat and can be custom shaped to fit in your vehicle in the location you require.
The base consists of three different legs: 18 inches, 20 inches and 30 inches, and at right angles to the base of the legs are feet with mounting holes. To mount the RAM-POD III, simply place the two of the feet holes into the passenger seat mounting bolts and adjust the mount to the required height with the flexible legs. The third flexible leg on the RAM Pod III should also be bolted under the dash of the vehicle, to help support the mount. The rigid flexible arms will hold everything you need safely and securely.
Installation Manual::Take a look at the assembly instructions (pdf file) of the RAM POD III (RAM-316-1A).
|
Features & Tips |
Here is a listing we have put together of some of the common Motion Computing LE1600 and LE1700 Vehicle Floor Mount features,
along with a few user tips that you may find of help for this particular item. | - Warranty: Manufacturer's Life Time Warranty.
- Cradle Design: Custom Cradle for Motion Computing LE1600 and LE1700 Tablet PC Series.
- Cradle Material: Black High Strength Composite Plastic.
- Mount Material: Black Powder Coated Marine Grade Aluminum with Aluminum Rod and High Strength Composite Plastic.
- Mount Ball Size: RAM 1 inch Solid Rubber Ball.
- Pivot Point Design: RAM Patented 1 inch Rubber Ball and Socket Joint.
- Arm Type: RAM Arm with Single 1 inch Socket and Single Octagon Button Socket.
- Arm Length: Short length of 1.75 inches between socket center and edge.
- Post Length: 18 inch Aluminum Rod.
- Base Type: Vehicle Floor Mount to be bolted into existing seat railing.
- Common Applications:
- Vehicle Mounts: Attaching to passengers seat rail bolt.
|
