This item has been discontinued by the manufacturer.
Accessories may still
be available for this item. Click to view accessories. |
| |
|
What's Included In The Box? |
The RAM Mount Lowrance iFinder Series Non Skid Flex Mount ships with the following items included: |
Product Information |
| Manufacturer: |
National Products, Inc |
Category: |
All Purpose Mounts |
Type: |
GPS Mounts |
| Model: |
RAP-169-LO2U |
SKU: |
RAP169LO2 |
UPC: |
793442801693 |
| Announced: |
January 1, 2008 |
First Shipped: |
January 1, 2008 |
Weight: |
4.300 lbs. |
Manufacturer Description |
The RAP-169-LO2 Lowrance iFinder Series RAM Mount is a Flex Arm Mount with a Weighted Non Skid Base and RAM Custom Plastic Cradle. The mount is designed with a 6 inch long Aluminum Flex Rod connecting the cradle and non-skid weighted base. Once the base is securely mounted, you can move the Lowrance iFinder Series cradle to your optimum viewing position with a simple bend of the arm.
Note: This mount does not require any drilling for installation.
Lowrance GPS Mount Cradle Design:
 The RAM-HOL-LO2 RAM Mount High Strength Plastic Cradle is designed to hold the Lowrance iFinder Series, including the following GPS units,
- Lowrance iFinder
- Lowrance iFinder Atlantis
- Lowrance iFinder Plus
- Lowrance iFinder Express
- Lowrance iFinder Pro
- Lowrance iFinder Pro Plus
- Lowrance AirMap 500
- Brunton Atlas
All cables can stay connected to the unit while in the RAM cradle.
Lowrance GPS Mount Arm Design:
 The RAM-B-201 RAM Mount Marine Grade Aluminum Dual Socket Arm is a 1 inch B size Ball Socket Arm with open socket ends. The arm is 3.0 inches long between socket centers and is finished with a Black Powder Coating. The side of the arm includes a tightening knob which allows you to open and close the socket ends. For a layout of the dimensions RAM-B-201 arm, take a closer look with the RAM-B-201 Design Drawings (pdf file).
Lowrance GPS Mount Base Design:The Non Skid rubber base consists of a flexible weighted lead core with molded rubber cover. The underside of the Non Skid base is a sticky material giving the weighted base a strong non-permanent hold on your dash. This base DOES NOT require any fastening to the mounting surface.
Lowrance GPS Mount Options:
To help ensure you have the Lowrance iFinder Mount you require, take a look at the list of available RAM Lowrance GPS mounts on the Lowrance iFinder Mount Page. Here you can select from suction cup GPS mounts, flat surface screw down GPS mounts, GPS car mounts, non skid weighted GPS mounts and more bundled with the RAM-HOL-LO2 Lowrance iFinder Series Cradle.
|
Features & Tips |
Here is a listing we have put together of some of the common Lowrance iFinder Series Non Skid Flex Mount features,
along with a few user tips that you may find of help for this particular item. | - Warranty: Manufacturer's Life Time Warranty.
- Cradle Design: Custom Cradle for Lowrance iFinder Series.
- Cradle Material: Black High Strength Composite Plastic.
- Mount Material: Black High Strength Composite Plastic with Aluminum Rod Arm and Lead Skeleton Base with Durable Rubber Coating.
- Pivot Point Design: Flexible Aluminum Arm.
- Arm Type: RAM Flexible Aluminum Rod.
- Arm Length: Aluminum Six (6) inch Long Aluminum Rod.
- Base Type: Lead Skeleton Weighted Base with Durable Rubber Coating - does not require any drilling to mount.
- Common Applications:
- Vehicle Mounts: Placed on vehicle dash or console (hardware not required).
|
