RAM Mount RAM-109H-2AU Aluminum Horizontal Base Dual Swing and Ball Arm Mount with 2.5'' dia Plate


RAM Mount Horizontal Swing Arm 4.63 inch Arm 2.5 inch Plate
Customer Images
Share your images and get a
free gpscity.ca t-shirt!
Not yet rated.    Email:  Email the RAM Mount Horizontal Swing Arm 4.63 inch Arm 2.5 inch Plate page     Print:  Print the RAM Mount Horizontal Swing Arm 4.63 inch Arm 2.5 inch Plate page
See more RAM Mount items.

List Price: $121.42CDN
Our Price: $96.95CDN   (Ships for $5.99. Restrictions apply.)
You Save: $24.47CDN (20%)

Availability:

In Stock.
Ships from Calgary on Monday, May 28.


Qty:

Model: RAM Mount Horizontal Swing Arm 4.63 inch Arm 2.5 inch Plate
Part No: RAM-109H-2AU
Condition: Brand New, Lifetime Manufacturer Warranty (max 3 years on electronics & lenses)
Price Match: Get an Instant Price Match in about 5 minutes (during business hours).

Learn More with our Instructional Videos

 » See our list of GPS City videos. Visit our Youtube channel.
RAM Round Plate: Overview (RAM-202U) Video
RAM Round Plate: Overview (RAM-202U)
(3,799 views)
RAM AMPS Hole Pattern: Explained Video
RAM AMPS Hole Pattern: Explained
(8,013 views)
RAM Mount Plate: Overview (RAM-B-347) Video
RAM Mount Plate: Overview (RAM-B-347)
(4,884 views)

Check out our

channel.


RAM Mount Sub-Component Breakdown

Here are the sub-component parts that make up this item:

Round Plate with 1.5 inch Ball RAM-202U
+
Standard Length Dual 1.5 inch Socket Arm RAM-201U
+
1.5 inch Ball on 0.63 inch dia Post RAM-208U
+
Straight Swing Arm Extension with 3 inch Bolt RAM-109-1ATPU
+
Horizontal Swing Arm Bolt Base RAM-109H-BU

What's Included In The Box?

The RAM Mount Horizontal Swing Arm 4.63 inch Arm 2.5 inch Plate ships with the following items included:


Product Information

Manufacturer: National Products, Inc Category: All Purpose Mounts Type: Swing Arm Mounts
Model: RAM-109H-2AU SKU: RAM109H-2A UPC:
Announced: November 30, 1999 First Shipped: July 10, 2002 Weight: 2.365 lbs.

Manufacturer Description

The RAM dual swing and socket arm mount consists of a 6'' long STRAIGHT swing arm mounted on a horizontal surface mounting base. At the device mounting end of the mount is a round 2.5'' diamater plate. The round plate is connected to the socket arm with a 1.5'' ball and socket system.

There are three (3) pivoting points on the mount. The connection between the swing arm and the base is a bolt pivot point, and the round plate to socket arm and the swing arm to socket arm connections have the RAM 1.5'' ball and socket system.

The bolt pivoting point allows a complete 360 degree rotation. The dual arm ball and socket system connection allows a 180 degree vertical pivot with a 360 degree rotation while the end plate ball and socket system allows a 180 degree vertical pivot with a 360 degree rotation.

Pictures of the RAM-109 Series Ball and Socket Systems:

Click for larger view of RAM 1.5'' Ball and Socket System End
The RAM-109 Plate Ball and Socket System
Click for larger view of RAM Arm 1.5'' Ball and Socket System End
The RAM-109 Arm Ball and Socket System
