Not yet rated. Email:
 Print:
See more RAM Mount items. |
| |
| List Price: |
$58.11CDN |
| Our Price: |
$44.95CDN (Ships for $5.99. Restrictions apply.) |
| You Save: |
$13.16CDN (23%) |
Availability: |
In Stock.
Ships from Calgary tomorrow, May 25. |
|
| |
| Model: |
RAM Mount Fujitsu LifeBook P1600 Series Tablet PC Yoke Mount |
| Part No: |
RAM-B-121-FUJ1 |
| Condition: |
Brand New, Lifetime Manufacturer Warranty (max 3 years on electronics & lenses) |
|
| Price Match: |
Get an Instant Price Match in about 5 minutes (during business hours). |
|
Learn More with our Instructional Videos |
| » See our list of GPS City videos. Visit our Youtube channel. |
RAM Rectangular Plate: Comparison Overview
(2,131 views) |
RAM Round Plate: Overview (RAM-B-202U)
(8,288 views) |
RAM AMPS Hole Pattern: Explained
(7,998 views) |
RAM Mount Plate: Overview (RAM-B-347)
(4,878 views) |
RAM Medium Arm: Overview (RAM-B-201U)
(21,910 views) |
|
What's Included In The Box? |
The RAM Mount Fujitsu LifeBook P1600 Series Tablet PC Yoke Mount ships with the following items included: |
Product Information |
| Manufacturer: |
National Products, Inc |
Category: |
All Purpose Mounts |
Type: |
Tablet Mounts |
| Model: |
RAM-B-121-FUJ1 |
SKU: |
RAMB121FUJ1 |
UPC: |
793442907234 |
| Announced: |
August 8, 2007 |
First Shipped: |
April 5, 2006 |
Weight: |
1.188 lbs. |
Manufacturer Description |
The RAM-B-121-FUJ1 Fujitsu LifeBook P1600 Series Tablet PC RAM Mount is a Marine Grade Aluminum Mount with a Yoke Clamp Base and RAM Custom Plastic Cradle. The mount is designed with a RAM 1 inch diameter patented rubber ball and socket system that has adjustment point at the cradle and base. With a twist of the arm knob, you can move the Fujitsu LifeBook P1600 Series Tablet PC mount to your optimum viewing position.
Fujitsu LifeBook Tablet Mount Options:
 To help ensure you have the Fujitsu LifeBook P1600 Series Mobile Tablet PC Mount you require, take a look at the list of available RAM Fujitsu Tablet mounts on the RAM-HOL-FUJ1 Series of Fujitsu LifeBook P1610 Mobile Tablet PC Cradles and Mounts Page. Here you can select from suction cup Tablet mounts, flat surface screw down Tablet mounts, Tablet car mounts, non skid weighted Tablet mounts and more bundled with the RAM-HOL-FUJ1 Fujitsu LifeBook P1610 Mobile Tablet PC Series Cradle.
Fujitsu LifeBook Tablet Mount Cradle Design:
The RAM-HOL-FUJ1 Fujitsu LifeBook P1600 Series RAM Mount Cradle is a High Strength Plastic Composite Cradle designed specifically to hold the Fujitsu LifeBook P1600 Series, including the following tablets units,
- Fujitsu LifeBook P1610 Mobile Tablet PC
- Fujitsu LifeBook P1620 Mobile Tablet PC
All cables can stay connected to the unit while in the RAM cradle.
Fujitsu LifeBook Tablet Mount Cradle Plate Design:
 The RAM-B-202 RAM Mount Marine Grade Aluminum Round Plate is designed to connected to the back of cradles with an AMPS hole pattern. The round plate has a 1.0 inch diameter rubber ball connected at right angles to the plate, which connects directly to the 1 inch arm socket. The cradle includes the required hardware to connect the plate to the cradle. For a layout of the hole spacing and 1.0 inch rubber ball location, take a closer look with the RAM-B-202 Design Drawings (pdf file).
Fujitsu LifeBook Tablet Mount Arm Design:
 The RAM-B-201 RAM Mount Marine Grade Aluminum Dual Socket Arm is a 1 inch B size Ball Socket Arm with open socket ends. The arm is 3.0 inches long between socket centers and is finished with a Black Powder Coating. The side of the arm includes a tightening knob which allows you to open and close the socket ends. For a layout of the dimensions RAM-B-201 arm, take a closer look with the RAM-B-201 Design Drawings (pdf file).
Fujitsu LifeBook Tablet Mount Base Design:
 The RAM-B-121B RAM Mount Powder Coated Marine Grade Aluminum Yoke Clamp Mount Base fits a rail diameter from 5/8 inch to a maximum of 1 1/4 inches. The 1 inch rubber ball is at a right angle to the plane of the mount so when connected to a rail, the ball sits parallel to the rail. To mount the base, simply place the yoke clamps around the rail and then screw the large knob at the end of the threaded rod. The hand tightened clamp makes this the perfect mounting system for rental planes and unusual shaped motorbike rails.
NOTE: The rail does not need to be perfectly round to mount this base.
|
Features & Tips |
Here is a listing we have put together of some of the common Fujitsu LifeBook P1600 Series Tablet PC Yoke Mount features,
along with a few user tips that you may find of help for this particular item. | - Warranty: Manufacturer's Life Time Warranty.
- Cradle Design: Custom Cradle for Fujitsu LifeBook P1610 and P1620 Tablet PC.
- Cradle Material: Black High Strength Composite Plastic.
- Mount Material: Black Powder Coated Marine Grade Aluminum.
- Mount Ball Size: RAM 1 inch Solid Rubber Ball.
- Pivot Point Design: RAM Patented 1 inch Rubber Ball and Socket Joint.
- Arm Type: RAM Arm with Dual 1 inch Sockets.
- Arm Length: Standard length of 3 inches between socket centers.
- Base Type: Yoke Clamp Base fits rails with diameter from 5/8 inch to a maximum of 1 1/4 inch
- Common Applications:
- Aviation Mounting: Attaching to the yoke on an aircraft.
- Temporary Mounting: Attaching to a round or odd shape pole or post.
|
