Not yet rated. Email:
 Print:
See more RAM Mount items. |
| |
| List Price: |
$40.91CDN |
| Our Price: |
$34.95CDN (Ships for $5.99. Restrictions apply.) |
| You Save: |
$5.96CDN (15%) |
Availability: |
In Stock.
Ships from Calgary today, May 24. |
|
| |
| Model: |
RAM Mount Camera Thread Rail Mount RAM-B-149Z-2-237 |
| Part No: |
RAM-B-149Z-2-237 (also RAM-B-149Z-2-237U) |
| Condition: |
Brand New, Lifetime Manufacturer Warranty (max 3 years on electronics & lenses) |
|
| Price Match: |
Get an Instant Price Match in about 5 minutes (during business hours). |
|
Learn More with our Instructional Videos |
| » See our list of GPS City videos. Visit our Youtube channel. |
RAM Camera Thread: Overview (RAM-B-237U)
(1,513 views) |
RAM Medium Arm: Overview (RAM-B-201U)
(21,910 views) |
Check out our
channel. | | |
|
What's Included In The Box? |
The RAM Mount Camera Thread Rail Mount RAM-B-149Z-2-237 ships with the following items included: |
Product Information |
| Manufacturer: |
National Products, Inc |
Category: |
All Purpose Mounts |
Type: |
Camera Mounts |
| Model: |
RAM-B-149Z-2-237 |
SKU: |
RAMB149Z-2-237 |
UPC: |
793442930010 |
| Announced: |
August 5, 2008 |
First Shipped: |
August 5, 2008 |
Weight: |
0.819 lbs. |
Manufacturer Description |
The RAM-B-149Z-2-237U Rail Strap RAM Mount is a Marine Grade Aluminum Mount with a Steel Clamp Strap Base and Camera Thread B-Ball. The male thread matches most standard camera and camcorder female threads found on the bottom of cameras. The pivot points for this mount consist of the RAM 1 inch diameter patented rubber ball and socket system and are located at the cradle plate and base ends. With a twist of the arm knob, you can move the camera thread mount to your optimum viewing position.
Camera Mount Options:
Camera Mount Design:
The RAM-B-237 Marine Grade Aluminum Universal Camera and Camcorder Thread Holder has a 1.0 inch diameter rubber ball connected to a male 1/4-20 camera thread. This male thread matches most standard camera and camcorder female threads found on the bottom of the camera.
Camera Mount Arm Design:
 The RAM-B-201 RAM Mount Marine Grade Aluminum Dual Socket Arm is a 1 inch B size Ball Socket Arm with open socket ends. The arm is 3.0 inches long between socket centers and is finished with a Black Powder Coating. The side of the arm includes a tightening knob which allows you to open and close the socket ends. For a layout of the dimensions RAM-B-201 arm, take a closer look with the RAM-B-201 Design Drawings (pdf file).
Camera Mount Base Design:
 The RAM-B-231-2 Marine Grade Aluminum Utility Strap Clamp Base has a 1.0 inch diameter Rubber Ball connected at right angles. The Strap Base tightening screw is encased in a compact housing for a clean, safe finish. The strap is long enough to wrap around handle bar posts found on most ATV, UTV, Snowmobiles, Motorcycles and any other applications you can think of.
Strap Dimensions: 1.57'' (40mm) to a maximum of 3.15'' (80mm).
|
Features & Tips |
Here is a listing we have put together of some of the common Camera Thread Rail Mount RAM-B-149Z-2-237 features,
along with a few user tips that you may find of help for this particular item. | - Warranty: Manufacturer's Life Time Warranty.
- Mount Ball Design: Camera Thread B-Ball to connect to a female camera thread.
- Mount Material: Black Powder Coated Marine Grade Aluminum.
- Mount Ball Size: RAM 1 inch Solid Rubber Ball.
- Pivot Point Design: RAM Patented 1 inch Rubber Ball and Socket Joint.
- Arm Type: RAM Arm with Dual 1 inch Sockets.
- Arm Length: Standard length of 3.0 inches between socket centers.
- Base Type: ATV/UTV base, Motorcycle Handlebar Base or Universal Round Pipe Base with Strap or Zinc Coated U-Bolt (0.75 to 1 inch wide)
- Common Applications:
- ATV/UTV Mounts: Attaching to handlebars.
- Motorcycle Mounts: Attaching to handlebars.
- Hiking Mounts: Attaching to hiking staffs.
- General Mounts: Attaching to available pipes or poles.
|
