| Model: |
RAM Mount Camera Thread Plate Mini Stainless Steel U-Bolt Mount |
| Part No: |
RAM-B-149-C1-319 |
| Condition: |
Brand New, Lifetime Manufacturer Warranty (max 3 years on electronics & lenses) |
|
| Price Match: |
Get an Instant Price Match in about 5 minutes (during business hours). |
|
| Learn More with our Instructional Videos (More GPS City videos.
Visit our Youtube channel.) |
RAM Camera Plate: Overview (RAM-B-202AU)
(2,440 views) |
RAM Medium Arm: Overview (RAM-B-201U)
(20,519 views) |
RAM Motorcycle U-Bolt Base: On Suzuki (RAM-B-231U)
(22,494 views) |
RAM Motorcycle U-Bolt Base: In the Box (RAM-B-231U)
(3,356 views) |
RAM Motorcycle U-Bolt Base: Overview (RAM-B-231U)
(6,707 views) |
|
| What's Included In The Box? |
The RAM Mount Camera Thread Plate Mini Stainless Steel U-Bolt Mount ships with the following items included: |
| Product Information |
| Manufacturer: |
National Products, Inc |
Category: |
All Purpose Mounts |
Type: |
Camera Mounts |
| Model: |
RAM-B-149-C1-319 |
SKU: |
RAMB149C1-319 |
UPC: |
|
| Announced: |
February 13, 2008 |
First Shipped: |
February 13, 2008 |
Weight: |
0.657 lbs. |
| Alternative Models For This Item |
RAM Mount Camera Thread Zinc U-Bolt Mount |
RAM Mount Camera Thread Plate Stainless Steel U-Bolt Mount |
RAM Mount Plastic Camera Handlebar Rail Mount |
RAM Mount Camera Long Arm Zinc U-Bolt Mount | | |
|
| RAM Mount Camera Thread Plate Mini Stainless Steel U-Bolt Mount Description |
The RAM-B-149-C1-319 Camera Thread Small Post RAM Mount is a Marine Grade Aluminum Mount with a Mini Stainless Steel U-Bolt Rail Base and RAM Plate with 1/4-20 Thread. The mount is designed with a RAM 1 inch diameter patented rubber ball and socket system that has adjustment point at the cradle and base. With a twist of the arm knob, you can move the camera mount to your optimum viewing position.
This mount is designed to be a universal mounting solution for both still and moving cameras.
Camera Mount Cradle Design:
The RAM-B-202A RAM Mount Powder Coated Marine Grade Aluminum Universal Camera Plate has a 1.0 inch diameter Rubber Ball connected at right angles to a 2.5 inch diameter Plate with a centered 1/4''-20 thread. The plate adds support to thread, allowing a more stable connection with the camera.
Note: The male 1/4'' long, 1/4''-20 thread in the middle of the 2.5'' diameter plate will connect to the standard female thread found at the bottom of most still and video cameras. An alternative to this camera mounting system is the RAM-B-237 Male 1/4''-20 Threaded Ball.
Camera Mount Arm Design:
 The RAM-B-201 RAM Mount Marine Grade Aluminum Dual Socket Arm is a 1 inch B size Ball Socket Arm with open socket ends. The arm is 3.0 inches long between socket centers and is finished with a Black Powder Coating. The side of the arm includes a tightening knob which allows you to open and close the socket ends. For a layout of the dimensions RAM-B-201 arm, take a closer look with the RAM-B-201 Design Drawings (pdf file).
Camera Mount Base Design:
The RAM-B-231-319 RAM Mount Powder Coated Marine Grade Aluminum Rail Base has a 1.0 inch diameter Rubber Ball designed to sit at right angles to the mounting rail. The Stainless Steel U-Bolt and nuts included are designed it fit on most motorcycle round handlebars, or any circular rail or pipe with diameter from 3/4 to 1.0 inch. Also included with this base is a RAP-319 u-bolt adapter. The RAM Mount u-bolt adapter narrows the u-bolt to a minimum with of approximately 1/2''. This is a great solution for the narrow handle bars of a scooter or support post of a motorcycle mirror.
To mount the rail base, place the top of the base on the rail and then slide the u-bolt, with adapter, around the rail, into the holes in the base top. Now tighten the screws onto the u-bolt until the base is clamped firmly. If you desire, you can now slot the black rubber covers over the exposed ends of the u-bolt.
|
| RAM Mount Camera Thread Plate Mini Stainless Steel U-Bolt Mount Features & Tips |
Here is a listing we have put together of some of the common Camera Thread Plate Mini Stainless Steel U-Bolt Mount features,
along with a few user tips that you may find of help for this particular item. | - Warranty: Manufacturer's Life Time Warranty.
- Cradle Design: Supporting plate with standard camera thread.
- Cradle Material: Black Powder Coated Marine Grade Aluminum.
- Mount Material: Black Powder Coated Marine Grade Aluminum.
- Mount Ball Size: RAM 1 inch Solid Rubber Ball.
- Pivot Point Design: RAM Patented 1 inch Rubber Ball and Socket Joint.
- Arm Type: RAM Arm with Dual 1 inch Sockets.
- Arm Length: Standard length of 3 inches between socket centers.
- Base Type: Motorcycle Handlebar Base or Universal Round Pipe Base with Stainless Steel U-Bolt (0.75 to 1 inch wide) and mini adapter (0.5 to 0.75 inch)
- Common Applications:
- Scooter Mounts: Attaching to handlebars.
- Vehicle Head Rest Mounts: Attaching to a vehicle head rest post.
- Motorcycle and ATV Mounts: Attaching to handlebars (without adapter) or mirror poles.
- Hiking Mounts: Attaching to hiking staffs.
- General Mounts: Attaching to available pipes or poles.
|
