See more RAM Mount items. |
| |
| List Price: |
$41.89CDN |
| Our Price: |
$34.95CDN (Ships for $5.99. Restrictions apply.) |
| You Save: |
$6.94CDN (17%) |
Availability: |
Ships by Friday, May 25, 2012. |
|
| |
|
|
| Model: |
RAM Mount Apple iPod Touch 4G Motorcycle Mount RAM-B-149-AP10U |
| Part No: |
RAM-B-149-AP10U (also RAM-B-149-AP10) |
| Condition: |
Brand New, Lifetime Manufacturer Warranty (max 3 years on electronics & lenses) |
|
| Price Match: |
Get an Instant Price Match in about 5 minutes (during business hours). |
|
Learn More with our Instructional Videos |
| » See our list of GPS City videos. Visit our Youtube channel. |
RAM Diamond Plate: Overview (RAM-B-238U)
(21,532 views) |
RAM AMPS Hole Pattern: Explained
(7,944 views) |
RAM Mount Plate: Overview (RAM-B-347)
(4,837 views) |
RAM Medium Arm: Overview (RAM-B-201U)
(21,865 views) |
RAM Motorcycle U-Bolt Base: On Suzuki (RAM-B-231U)
(25,128 views) |
|
What's Included In The Box? |
The RAM Mount Apple iPod Touch 4G Motorcycle Mount RAM-B-149-AP10U ships with the following items included: |
Product Information |
| Manufacturer: |
National Products, Inc |
Category: |
All Purpose Mounts |
Type: |
iPod Mounts |
| Model: |
RAM-B-149-AP10U |
SKU: |
RAMB149AP10 |
UPC: |
|
| Announced: |
February 11, 2011 |
First Shipped: |
March 11, 2011 |
Weight: |
0.700 lbs. |
Manufacturer Description |
The RAM-B-149-AP10 Apple iPod Touch 4G Motorcycle RAM Mount is a Marine Grade Aluminum Mount with a Stainless Steel U-Bolt Rail Base and RAM Custom Plastic Cradle. The mount is designed with a RAM 1 inch diameter patented rubber ball and socket system that has adjustment point at the cradle and base. With a twist of the arm knob, you can move the Apple iPod Touch 4G mount to your optimum viewing position.
Apple iPod and iPhone Identity and Mount Page:
 If you are unsure of what model Apple iPad, iPod classic, iPod nano, iPod mini, iPod touch or iPhone you have, now you can review your Apple device features on our Apple iPod, iPad and iPhone Identify Page. Once you identify your Apple iPod, iPad or iPhone, you can the select the right mount for your model.
Apple iPod Touch Mount Options:
Apple iPod Touch Mount Cradle Design:
Apple iPod Touch Mount Cradle Plate:
 The RAM-B-238 Marine Grade Aluminum Diamond Plate is designed to connected to the back of the mount cradle. The diamond plate has a 1.0 inch diameter rubber ball connected at right angles to the plate, which connects directly to the 1 inch arm socket. The cradle includes the required hardware to connect the plate to the cradle. For a layout of the hole spacing and 1.0 inch rubber ball location, take a closer look with the RAM-B-238 Design Drawings (pdf file).
Apple iPod Touch Mount Arm Design:
 The RAM-B-201 RAM Mount Marine Grade Aluminum Dual Socket Arm is a 1 inch B size Ball Socket Arm with open socket ends. The arm is 3.0 inches long between socket centers and is finished with a Black Powder Coating. The side of the arm includes a tightening knob which allows you to open and close the socket ends. For a layout of the dimensions RAM-B-201 arm, take a closer look with the RAM-B-201 Design Drawings (pdf file).
Apple iPod Touch Mount Base Design:
 The RAM-B-231 RAM Mount Powder Coated Marine Grade Aluminum Rail Base has a 1.0 inch diameter Rubber Ball designed to sit at right angles to the mounting rail. The Stainless Steel U-Bolt and nuts included are designed it fit on most motorcycle round handlebars, or any circular rail or pipe with diameter from 3/4 to 1.0 inch.
To mount the rail base, place the top of the base on the rail and then slide the u-bolt around the rail, into the holes in the base top. Now tighten the screws onto the u-bolt until the base is clamped firmly. If you desire, you can now slot the black rubber covers over the exposed ends of the u-bolt.
NOTE: This base is completely rust proof.
For Larger Rail Mounting:
For a larger rail, you can purchase the RAM Mount Stainless Steel Large Rail U-Bolt for circular rails with diameter up to 1.25 inches.
|
Features & Tips |
Here is a listing we have put together of some of the common Apple iPod Touch 4G Motorcycle Mount RAM-B-149-AP10U features,
along with a few user tips that you may find of help for this particular item. | - Warranty: Manufacturer's Life Time Warranty
- Cradle Design: Custom Cradle for Apple iPod touch 4th Generation
- Cradle Material: High Strength Plastic
- Mount Material: Black Powder Coated Marine Grade Aluminum
- Mount Ball Size: RAM 1 inch Solid Rubber Ball
- Pivot Point Design: RAM Patented RAM 1 inch Rubber Ball and Socket Joint
- Arm Type: RAM Arm with Dual 1 inch Sockets
- Arm Length: Standard length of 3 inches between socket centers
- Base Type: Motorcycle Handlebar Base or Universal Round Pipe Base with Stainless Steel U-Bolt
- Common Applications:
- Motorcycle and ATV Mounts: Attaching to handlebars.
- Hiking Mounts: Attaching to hiking staffs.
- General Mounts: Attaching to available pipes or poles.
|
