| Model: |
Lowrance Elite-5 Fishfinder and GPS Chartplotter |
| Part No: |
104-001 |
| Condition: |
Brand New, Full Manufacturer Warranty |
|
| Price Match: |
Get an Instant Price Match in about 5 minutes (during business hours). |
|
Learn More with our Instructional Videos |
| » See our list of GPS City videos. Visit our Youtube channel. |
Lowrance Elite 5: Muting Sounds & Beeps
(73 views) |
Lowrance Elite 5 DSI: Enabling GPS Grid Lines
(14,178 views) |
Lowrance Elite 5: Change Languages
(738 views) |
Lowrance Elite 5 DSI: Adjust Views
(6,333 views) |
Lowrance Elite 5 DSI: Setting the GPS Source
(3,668 views) |
|
Most Popular Elite-5 Fishfinder and GPS Chartplotter Accessories
» View the complete accessory list for the Lowrance Elite-5 Fishfinder and GPS Chartplotter. |
Lowrance Elite 5 Series Cover
$24.95
|
RAM Mount Humminbird Screw Down Large Marine Mount
$46.95
|
RAM Mount Lowrance and Humminbird Marine Rail Mount RAM-107-231U
$51.95
|
Lowrance LGC-16W Elite Series External GPS Antenna
$79.95
|
Navionics Gold microSD USA and Northern Bahamas
$199.95
|
Navionics Gold microSD Canada Coastal Waters and SE Alaska
$249.95
|
What's Included In The Box? |
The Lowrance Elite-5 Fishfinder and GPS Chartplotter ships with the following items included: - Lowrance Elite-5 Fishfinder and GPS Chartplotter (View this item)
- Power/Transducer Cable
- Transom Mount 83/200khz transducer
- Power/data cable
- Base mount
- Document Pack and a One-Year Warranty
|
Product Information |
| Manufacturer: |
Lowrance |
Category: |
GPS Units |
Type: |
Marine GPS |
| Model: |
104-001 |
SKU: |
LM-ELITE5 |
UPC: |
042194534886 |
| Announced: |
May 26, 2010 |
First Shipped: |
May 26, 2010 |
Weight: |
4.010 lbs. |
Lowrance Elite-5 Fishfinder and GPS Chartplotter Family Series |
Lowrance Elite-5 Gold Fishfinder and GPS Chartplotter |
Lowrance Elite-5x Fishfinder |
Lowrance Elite-5m GPS Chartplotter |
Lowrance Elite-5m Gold GPS Chartplotter | | |
|
Lowrance Elite-5 Fishfinder and GPS Chartplotter Alternative Models |
Lowrance Elite-5 DSI Fishfinder and GPS Chartplotter |
Lowrance Elite-5x DSI Color Fishfinder |
Lowrance Elite-5 DSI Gold Fishfinder and GPS Chartplotter | | | |
|
Manufacturer Description |
Powerful fishfinder functionality, precision GPS chartplotter features and a high-quality 5 in./12.7 cm color display - all in a well-priced package.
- True 12.7 cm/5 in., 480x480 pixel SolarMAX™ 256-colour TFT display
- 500 W RMS, 4,000 W PTP; depth to 305 m/1,000 ft.
- Dual-frequency 83/200 kHz fishfinding
- Internal 16-channel GPS antenna
- Built-in background mapping/charting
- Navionics® and other chart options
The new color Elite-5 fishfinder/chartplotter brings high performance and high color to on-the-water enjoyment in every way, and without a high price. You enjoy incredible precision and functionality, in addition to a spectacular new view.
The brilliant 5 in./12.7 cm, 480x480 pixel SolarMAX™ 256-color TFT display has unmatched screen brightness, contrast, resolution and viewing detail at wider angles and in bright sunlight. Adjustable screen and keypad backlight improves usability and visibility day or night.
The 500W RMS sounder reaches depth of 1,000'/305 m with its dual-frequency 83/200 kHz Skimmer® transom-mount transducer with internal temp sensor and up to 120 degrees of wider sonar coverage. Unique TrackBack™ feature offers immediate scroll-back to review multiple pages of fishfinder history.
The internal 16-channel GPS antenna provides great WAAS+EGNOS+MSAS precision for navigation. And an external antenna option is also available for customized applications. A waterproof microSD memory card slot is fully compatible with Navionics® Gold chartcards, as well as Fishing Hot Spots® and LakeMaster® mapcards in the microSD format for U.S. anglers. Built-in memory allows for up to 3,000 waypoints, 100 routes/100 waypoints per route and 100 retraceable plot trails/up to 10,000 points per trail.
All of this, packaged with easy-to-use menus with Advanced Mode to expand features selection. An all-new case/mounting design provides for easy one-hand tilt/swivel view adjustment, removal and re-install - even fits same cut-out for previous 5 in./7 cm models for in-dash installations. And a new uniplug 1/4-turn connectors are compatible with earlier Lowrance uniplug installations to simplify upgrades to any new Elite model.
|
Features & Tips |
Here is a listing we have put together of some of the common Elite-5 Fishfinder and GPS Chartplotter features,
along with a few user tips that you may find of help for this particular item. | DISPLAY
- Display Size: 5 in \ 127 mm
- Display Resolution: 480x480 (H x W)
- Display Type: 256-color SolarMAX™ PLUS TFT
- Backlighting: Flourescent cold cathode
- Backlighting Levels: Adjustable screen/keypad
- Languages Supported: 23
SONAR / SOUNDER
- Sonar Frequency: 83/200 kHz
- Transducer Type: Skimmer®
- Sonar Output Power: Max 500W RMS, 4000W PTP W
- Sonar Depth: Max 1000 ft \ 305 m
- Sonar Alarms: Fish, Max and Min Depth Yes
- Depth Alarm: Yes
- Shallow Alarm: Yes
- Temperature Display: Yes
GPS / NAVIGATION
- GPS Antenna Type: Internal high-sensitivity WAAS + EGNOS + MSAS (optional external antenna)
GPS Receiver Channels: 16 channels
- Background Map: World reference basemap or (U.S. models) over 3,000 enhanced lake maps with depth contour and shoreline detail, plus coastal depth contours/shoreline detail and spot depth soundings to 1,000 ft./305 m
- Custom Mapping: Optional Navionics® Gold chartcards (U.S. & worldwide) and Fishing Hot Spots® and LakeMaster® mapcards (U.S.) in microSD format
- Waypoint Storage: 3000
- Route:s 100
- Plot Trails: 100 retraceable plot trails/up to 10,000 points per trail
- GPS Alarm:s Yes
NETWORKING / CONNECTORS
TECHNICAL / ENVIRONMENTAL
- Built-in Backup Memory: Yes
- Waterproof Standard: Sealed and waterproof, suitable for saltwater use
- Width: 6.9 in \ 174 mm
- Height: 5.4 in \ 136 mm
- Depth: 2.5 in \ 63 mm
POWER
OTHER
- Memory Card Capable: One (1) waterproof microSD card slot
- Other Features: Unique TrackBack™ feature offers immediate scroll-back to review multiple pages of fishfinder history
|
