RAM Mount Aluminum Symbol Motorola MC70 Powered Locking Suction Cup Mount

   ATTENTION!  This item has a NEW & IMPROVED page format. Please click this link to view the new page.

RAM Mount Symbol Motorola MC70 Powered Locking Suction Cup Mount
Click image for larger view
Mfg P/N: RAM-B-166-SYM1P
SKU: RAMB166SYM1P

Share this item: Facebook DiggDelIcioUs
 $109.95
Price shown in CAD currency

In Stock! Ships by 2PM MST today, February 9.

Qty:


This item is Brand New (not refurbished), and has a Lifetime Warranty (excluding electronic or lense components)

Found a lower price? Let us know!

POPULAR SYMBOL MOTOROLA MC70 POWERED LOCKING SUCTION CUP MOUNT ACCESSORIES!!
GPS CITY

Super Grip Dashboard Friction Mount Base
$15.95

RAM MOUNT

Black Rose Adhesive Plate for Suction Cups
$5.68

RAM MOUNT

Black Large Adhesive Plate for Suction Cups
$4.38

RAM MOUNT

Clear Large Adhesive Plate for Suction Cups
$4.38

RAM MOUNT

RAM-A-CAN II Vehicle Cup Flat Surface Base
$19.95

Even MORE ACCESSORIES below!!


JUMP TO: (Use these links to quickly jump down to a section of the page)
Accessories
Product Features		 Customer Reviews
What's In The Box?		 Product Videos
Product Tips		 Family Tree
Alternative Units



SYMBOL MOTOROLA MC70 POWERED LOCKING SUCTION CUP MOUNT PRODUCT DETAILS
 Back to Top

The RAM-B-166-SYM1P Symbol Motorola MC70 Series Powered Windshield Suction RAM Mount is a Marine Grade Aluminum Mount with a Locking Suction Cup Base and RAM Custom Plastic Cradle. The mount is designed with a RAM 1 inch diameter patented rubber ball and socket system that has adjustment point at the cradle and base. With a twist of the arm knob, you can move the Symbol Motorola MC70 Mobile Computing Series Powered mount to your optimum viewing position.

Note: This mount does not require any drilling for installation.

Mobile Computing Mount Options:


To help ensure you have the Symbol Motorola MC70 Mobile Computer Mount you require, take a look at the list of available RAM Symbol Motorola MC70 mounts on the RAM-HOL-SYM1 Series of Symbol Motorola MC70 Mobile Computer Cradles and Mounts Page. Here you can select from suction cup Mobile Computer mounts, flat surface screw down Mobile Computer mounts, Mobile Computer car mounts, non skid weighted Mobile Computer mounts and more bundled with the RAM-HOL-SYM1 Symbol Motorola MC70 Mobile Computer Series Cradle.

Mobile Computing Mount Cradle Design:


The RAM-HOL-SYM1P RAM Mount High Strength Plastic Powered Cradle with Spring Clamp is designed to hold the Symbol Motorola MC70 Mobile Computer. This custom cradle connects to the RAM assembly mounts with a 2.5 inch diamter round plate (RAM-B-202 or RAM-202).

Mobile Computing Mount Cradle Plate:


The RAM-B-202 RAM Mount Marine Grade Aluminum Round Plate is designed to connected to the back of cradles with an AMPS hole pattern. The round plate has a 1.0 inch diameter rubber ball connected at right angles to the plate, which connects directly to the 1 inch arm socket. The cradle includes the required hardware to connect the plate to the cradle. For a layout of the hole spacing and 1.0 inch rubber ball location, take a closer look with the RAM-B-202 Design Drawings (pdf file).

Mobile Computing Mount Arm Design:


The RAM-B-201 RAM Mount Marine Grade Aluminum Dual Socket Arm is a 1 inch B size Ball Socket Arm with open socket ends. The arm is 3.0 inches long between socket centers and is finished with a Black Powder Coating. The side of the arm includes a tightening knob which allows you to open and close the socket ends. For a layout of the dimensions RAM-B-201 arm, take a closer look with the RAM-B-201 Design Drawings (pdf file).

Mobile Computing Mount Base Design:


The RAM-B-224-1 RAM Mount Plastic Locking 3.25 inch diameter Rubber Suction Cup Base, with Marine Grade Aluminum Diamond Plate, is designed to have an extra strong hold on any smooth non-porous surface. With a twist on the locking knob, the suction cup base adheres to any glass¹ or non-porous plastic surface, as found on our Non Skid Base with Plastic Disk and Plastic Adhesive Disk.

Connected to the top of the Suction Cup is a RAM-B-238 RAM Mount Marine Grade Aluminum Diamond Plate with 1 inch diameter Rubber Ball. This plate allows the suction cup to join to an open socket found on the RAM 1 inch diameter socket arms.

¹ Important legal note to California and Minnesota Drivers

Suction Cup Base Mounting Options:

We currently offer three alternative solutions for mounting your suction cup mount in a location other than a windshield:
  • The Super Grip Non Skid Base with round plastic plate, is a weighted base that can be placed on your dash without an adhesive or drilling. Simply place the base on your dash, or any flat surface and then attach the suction cup to the round plastic plate. This is perfect when you want a temporary mounting solution but the windshield mount just isn't the answer.

  • The Suction Cup Adhesive Disk with round plastic plate, is a great mounting surface to attach the RAM Twist Lock Suction Cup. Simply stick the the plate to any flat surface and then attach the suction cup to the plate. This is perfect when you need to attach your suction cup mount to your car dash vertically or horizontally, rather than to your windshield.

  • The Suction Cup Drink Cup Holder with round plastic plate, is a great mounting surface to attach the RAM Twist Lock Suction Cup. Simply place the base into any cup holder in your vehicle and then attach the suction cup to the plate found on top. This is perfect when you need to attach your suction cup mount away from the windshield or when you just want the mount off the dash.



SYMBOL MOTOROLA MC70 POWERED LOCKING SUCTION CUP MOUNT PRODUCT FEATURES
 Back to Top

  • Warranty: Manufacturer's Life Time Warranty.
  • Cradle Design: Custom Powered Cradle for Symbol Motorola MC70 Mobile Computer Series.
  • Cradle Material: Black High Strength Composite Plastic.
  • Mount Material: Black Powder Coated Marine Grade Aluminum and Plastic and Rubber Locking Suction Cup.
  • Mount Ball Size: RAM 1 inch Solid Rubber Ball.
  • Pivot Point Design: RAM Patented 1 inch Rubber Ball and Socket Joint.
  • Arm Type: RAM Arm with Dual 1 inch Sockets.
  • Arm Length: Standard length of 3 inches between socket centers.
  • Base Type: Round 3.25 inch diameter Locking Suction Cup for non-porous surfaces
  • Common Applications:



SYMBOL MOTOROLA MC70 POWERED LOCKING SUCTION CUP MOUNT WHAT'S IN THE BOX?
 Back to Top

1. RAM Mount Powered Symbol Motorola MC70 Cradle (RAM-HOL-SYM1PU)
2. RAM Mount Round Plate with 1 inch Ball RAM-B-202U (RAM-B-202U)
3. RAM Mount Medium Arm B-Socket RAM-B-201U (RAM-B-201U)
4. RAM Mount Diamond Plate with 1 inch Ball RAM-B-238U (RAM-B-238U)
5. RAM Mount Locking Suction Mount Base RAP-224-1U (RAP-224-1U)




SYMBOL MOTOROLA MC70 POWERED LOCKING SUCTION CUP MOUNT CUSTOMER REVIEWS
Back to Top

Click here to Add Your Own Review. It's quick and easy! No login required.

There are currently no reviews for this product. If you have comments on this product that you would like to share with other users, please feel free to write a quick review using the form below. Thank you!
