GPS Mounts > Garmin Mounts

RAM Mount Aluminum Garmin GPS II III V Series Zinc Coated U-Bolt Motorcycle Mount

   ATTENTION!  This item has a NEW & IMPROVED page format. Please click this link to view the new page.

RAM Mount Garmin GPS V Series Zinc U-Bolt Mount
Click image for larger view
Mfg P/N: RAM-B-149Z-GA2U
SKU: RAMB149ZGA2

Share this item: Facebook DiggDelIcioUs
 $31.95
Price shown in CAD currency

In Stock! Ships by 2PM MST today, February 9.

Qty:


This item is Brand New (not refurbished), and has a Lifetime Warranty (excluding electronic or lense components)

Found a lower price? Let us know!

 More Images...
RAM Mount Garmin GPS V Series Zinc U-Bolt Mount


JUMP TO: (Use these links to quickly jump down to a section of the page)
Accessories
Product Features		 Customer Reviews
What's In The Box?		 Product Videos
Product Tips		 Family Tree
Alternative Units



GARMIN GPS V SERIES ZINC U-BOLT MOUNT PRODUCT DETAILS
 Back to Top

The RAM-B-149Z-GA2 Garmin Garmin GPS II, III and V Series Motorcycle RAM Mount is a Marine Grade Aluminum Mount with a Zinc Coated U-Bolt Rail Base and RAM Custom Plastic Cradle. The mount is designed with a RAM 1 inch diameter patented rubber ball and socket system that has adjustment point at the cradle and base. With a twist of the arm knob, you can move the Garmin GPS II, III and V Series (including Garmin GPS II, II Plus, III, III Plus, III Pilot and V) mount to your optimum viewing position.

Garmin GPS Mount Options:


To help ensure you have the Garmin GPS II, III and V Series Mount you require, take a look at the list of available RAM Garmin GPS mounts on the RAM-HOL-GA2 Series of Garmin GPS II, III and V Cradles and Mounts Page. Here you can select from suction cup GPS mounts, flat surface screw down GPS mounts, GPS car mounts, non skid weighted GPS mounts and more bundled with the RAM-HOL-GA2 Garmin GPS II, III and V Series Cradle.

Garmin GPS Mount Cradle Design:


The RAM-HOL-GA2 RAM Mount High Strength Plastic Cradle is designed to hold the Garmin GPS II, III and V Series, including the following GPS units,
  • Garmin GPS II
  • Garmin GPS II+
  • Garmin GPS III
  • Garmin GPS III+
  • Garmin GPS V
  • Garmin GPS V Deluxe
The RAM-HOL-GA2 cradle can rotate to allow viewing the GPS unit with the vertical or horizontal screen and all cables can stay connected to the unit while in the RAM cradle.

Garmin GPS Mount Cradle Plate:


The RAM-B-238 Marine Grade Aluminum Diamond Plate is designed to connected to the back of the mount cradle. The diamond plate has a 1.0 inch diameter rubber ball connected at right angles to the plate, which connects directly to the 1 inch arm socket. The cradle includes the required hardware to connect the plate to the cradle. For a layout of the hole spacing and 1.0 inch rubber ball location, take a closer look with the RAM-B-238 Design Drawings (pdf file).

Garmin GPS Mount Arm Design:


The RAM-B-201 RAM Mount Marine Grade Aluminum Dual Socket Arm is a 1 inch B size Ball Socket Arm with open socket ends. The arm is 3.0 inches long between socket centers and is finished with a Black Powder Coating. The side of the arm includes a tightening knob which allows you to open and close the socket ends. For a layout of the dimensions RAM-B-201 arm, take a closer look with the RAM-B-201 Design Drawings (pdf file).

Garmin GPS Mount Base Design:


The RAM-B-231Z RAM Mount Powder Coated Marine Grade Aluminum Rail Base has a 1.0 inch diameter Rubber Ball designed to sit at right angles to the mounting rail. The Zinc Coated metal U-Bolt and nuts included are designed it fit on most motorcycle round handlebars, or any circular rail or pipe with diameter from 3/4 to 1.0 inch.

To mount the rail base, place the top of the base on the rail and then slide the u-bolt around the rail, into the holes in the base top. Now tighten the screws onto the u-bolt until the base is clamped firmly. If you desire, you can now slot the black rubber covers over the exposed ends of the u-bolt.

Note: If you are looking to use this mount in the elements, we suggest the RAM-B-231 Stainless Steel U-Bolt Mount.

For Small Rail Mounting:

For a smaller rail, you can purchase the RAP-319 RAM Mount Plastic U-Bolt Adapter for circular rails with diameter down to 0.5 inches.

For Larger Rail Mounting:

For a larger rail, you can purchase the RAM Mount Stainless Steel Large Rail U-Bolt for circular rails with diameter up to 1.25 inches.



GARMIN GPS V SERIES ZINC U-BOLT MOUNT PRODUCT FEATURES
 Back to Top

  • Warranty: Manufacturer's Life Time Warranty.
  • Cradle Design: Custom Cradle for Garmin GPS II III and V Series.
  • Cradle Material: Black High Strength Composite Plastic.
  • Mount Material: Black Powder Coated Marine Grade Aluminum.
  • Mount Ball Size: RAM 1 inch Solid Rubber Ball.
  • Pivot Point Design: RAM Patented 1 inch Rubber Ball and Socket Joint.
  • Arm Type: RAM Arm with Dual 1 inch Sockets.
  • Arm Length: Standard length of 3 inches between socket centers.
  • Base Type: Motorcycle Handlebar Base or Universal Round Pipe Base with Zinc Coated U-Bolt. (0.75 to 1 inch wide)
  • Common Applications:
    • Motorcycle and ATV Mounts: Attaching to handlebars.
    • Hiking Mounts: Attaching to hiking staffs.
    • General Mounts: Attaching to available pipes or poles.



GARMIN GPS V SERIES ZINC U-BOLT MOUNT WHAT'S IN THE BOX?
 Back to Top

1. RAM Mount Garmin GPS II III and V Series Cradle (RAM-HOL-GA2U)
2. RAM Mount Diamond Plate with 1 inch Ball RAM-B-238U (RAM-B-238U)
3. RAM Mount Medium Arm B-Socket RAM-B-201U (RAM-B-201U)
4. RAM Mount Zinc U-Bolt Motorcycle Mount Base RAM-B-231ZU (RAM-B-231ZU)




GARMIN GPS V SERIES ZINC U-BOLT MOUNT CUSTOMER REVIEWS
Back to Top

Click here to Add Your Own Review. It's quick and easy! No login required.



Bill
Vancouver, BC
May 26, 2009
 		 EXCELLENT MOTORCYCLE MOUNT

Pros: well made and simple to use and install
Cons: none
The RAM GPS V U-Bolt mount is well designed and very easy to install on a motorcycle. As well,it has a large range of movement allowing the user to adjust the GPS exactly to their line of vision. The product is rugged and well made and simple to adjust, even while riding.This is my second purchase of the above mount--the first having been in service for many years in all kinds of weather. I would highly recommend any of the RAM products and the excellent pricing and service of GPSCITY.

20 out of 39 viewers found this review helpful.

Was this review helpful to you?   Yes   No




T/A - Mike
Oxford, Ct.
April 23, 2009
 		 GPS MOUNT

RAM mounts are very easy to put on and keep the GPS nice and stable during rough riding on my ATV. I also use them on the snowmobile and they are awesome.

27 out of 51 viewers found this review helpful.

Was this review helpful to you?   Yes   No





GARMIN GPS V SERIES ZINC U-BOLT MOUNT ALTERNATIVE UNITS
 Back to Top

RAM MOUNT
RAM Mount Garmin GPS V Series Zinc U-Bolt Mount (RAM-B-149Z-GA2U)
 Garmin GPS V Series Zinc U-Bolt Mount		RAM MOUNT
RAM Mount GPS V Series Stainless Steel U-Bolt Mount (RAM-B-149-GA2U)
 GPS V Series Stainless Steel U-Bolt Mount		RAM MOUNT
RAM Mount RAP-B-149-GA2 (RAP-B-149-GA2U)
 RAP-B-149-GA2
