Garmin GPSMAP 76 76S: Overview
(3,548 views) |
Garmin GPSMAP 76 76S: GPS Customize Map Screen
(3,384 views) |
Garmin GPSMAP 76 76S: BlueChart and Street Maps
(7,141 views) |
Garmin GPSMAP 76S: Internal Sensors
(2,076 views) |
Check out our
channel. |
|
Most Popular GPSMAP 76S Accessories
» View the complete accessory list for the Garmin GPSMAP 76S. |
RAM Mount GPSMAP 76 76S Series Locking Suction Cup Mount
$36.95
|
RAM Mount GPS 76 GPSMAP 76 Stainless Steel U-Bolt Mount
$36.95
|
Garmin Handheld Nylon Case
$8.95
|
Garmin Cigarette Lighter Adapter
$19.95
|
|
|
What's Included In The Box? |
The Garmin GPSMAP 76S ships with the following items included: |
Product Information |
| Manufacturer: |
Garmin |
Category: |
GPS Units |
Type: |
Outdoor GPS |
| Model: |
010-00271-00 |
SKU: |
76MAPS |
UPC: |
753759032029 |
| Announced: |
February 1, 2002 |
First Shipped: |
April 16, 2002 |
Weight: |
1.244 lbs. |
Garmin GPSMAP 76S Family Series |
Garmin GPSMAP 76 |
Garmin GPSMAP 76S |
Garmin GPSMAP 76C |
Garmin GPSMAP 76CS | | |
|
Manufacturer Description |
As with the original units in the GPSMAP 76 series, the GPSMAP 76S is also designed to provide precise GPS positioning using correction data obtained from the Wide Area Augmentation System. This unit features a built-in quad helix antenna for superior reception and can provide position accuracy to less than three meters when receiving WAAS corrections.
The GPSMAP 76S comes with a built-in basemap of North and South America, including major highways, thoroughfares, rivers, lakes, and borders. The internal memory has been increased to a very useful 24 Megabytes for downloading MapSource data. An extra-large display measuring 1.6''W x 2.2''H, which is standard for all of the GPS 76 Series, gives users a clear view of information, while a waterproof case means the GPSMAP 76S will keep working well even if it's been submerged in water. Even more amazing, this units will actually float if accidentally dropped in the water.
If you're a devoted mariner or serious outdoor enthusiast, our new GPSMAP 76S is the GPS/mapping unit for you. The ''S'' in the product name stands for ''sensors'', because the GPSMAP 76S incorporates a GPS receiver, barometric altimeter, and an electronic compass that deliver precise location, elevation, and bearing information to take adventurers as high or as far as they want to go.
SOFTWARE UPGRADES FROM GARMIN:
Increase Waypoint/Tracklog Storage:
Upgrade 3.10, and above, for the GPSMAP 76S now includes an increased active track log to 10,000 points, an increased saved track log to 750 points, an increased user waypoints to 1,000 waypoints and an increased waypoints per route to 125 waypoints.
Click here for unit software upgrade.
Glide Ratio:
Upgrade 2.01, and above, for the GPSMAP 76S now includes glide ratio, glide ratio to target, and vertical speed to target as choices for all configurable fields.
Click here for unit software upgrade. |
|
Features & Tips |
Here is a listing we have put together of some of the common GPSMAP 76S features,
along with a few user tips that you may find of help for this particular item. | • WAAS enabled, 12 parallel channel GPS receiver
• Built-in quad helix receiving antenna with remote antenna capability
• Electronic compass displays accurate heading while standing still
• Barometric sensor with automatic pressure trend recording
• Unit dimensions 6.2'' high x 2.7'' wide x 1.2'' D
• Display: 1.6''W x 2.2''H, high resolution FSTN, 4 level grayscale (180 x 240 pixels)
• Weight: 7.6 ounces with batteries
• Backlit display and keypad
• Battery life: 10 to 12 hours (typical use), two AA alkaline batteries
• Permanent user data storage; no memory battery required
• Water resistant, IEC-529, IPX7 (Submersible 1 meter @ 30 minutes) and it floats
• 500 user waypoints with name and graphic symbol; 50 reversible routes
• Position formats include Lat/Lon, UTM, Loran TDs, Maidenhead, MGRS and user grid
• Audible alarms for anchor drag, arrival, off-course, proximity waypoint and clock
• Large numbers option for easy viewing
• Built-in basemap showing cities, interstates, coastlines and more
• 24-Mbyte internal memory for loading MapSource detail including BlueChart
• Trip computer provides odometer, stopped time, moving average, overall average, total time, max speed and more
• Elevation computer provides current elevation, ascent/descent rate, minimum and maximum elevation, total ascent and descent, average and maximum ascent and descent rate.
• 5000 point automatic track log; 10 saved tracks let you retrace your path in both directions
• Course and speed filtering
• Built-in celestial tables for best times to fish and hunt, plus sun and moon calculations
• Compatible with most MapSource products, including BlueChart, Fishing Hot Spots, Topo and MetroGuide. |
